AC/DC Dual mode | Dual channel fast charge
Synchronous Parallel charging | 2.4″ IPS LCD Display

K1
K1

AC/DC dual mode

AC/DC dual input meet different use requirements.
Output: AC 100W / DC 250W x2

AC/DC dual mode

AC/DC dual input meet different use requirements. Output: AC 100W / DC 250W x2

K1

Safe access

Fool-proof input interface. Smart design
The DC input port and AC input port are mutually exclusive.
Only one input can be selected in one time,
Ensure the safety operation.

K1

Safe access

Fool-proof input interface. Smart design
The DC input port and AC input port are mutually exclusive.
Only one input can be selected in one time,
Ensure the safety operation.

K1

High Power Synchronous Dual Channel, with Smart Charging.

Smart High Speed Processor delivers parameter interfere to each port.
Hassle Free with Maximum charging power up to 250W for single port.
Choose ISDT, Powered by Innovation.

Upgradeable
Firmware

By connecting the charger USB-C port to the PC,
K1 can acquire latest firmware upgrading,
ensure the charger have optimalized performance and latest firmware all the time.

Upgradeable Firmware

By connecting the charger USB-C port to the PC,
K1 can acquire latest firmware upgrading,
ensure the charger have optimalized performance and latest firmware all the time.

K1
K1

Upgraded scOS 2.0, not only optimizing the system
with a new dimension level,
also further improved the system stability.
New features including DC Power mode,
dark mode, battery scrap and more.
Streamline support with BattGo and SmartPower,
for further interconnection to ISDT ecosystem
product information exchange.

Adjustable Digital Power Supply.

In adjustable digital power supply mode,
the Max. power is AC 100W / DC 120W.
CC: 0.2~5.0A
CV: 5~24V

Introducing the dark mode.

scOS 2.0 new dark mode feature,
Suitable for low light scenario,
System will adjust the interface in dark tone,
Reduce light damage to user’s eyes.
While remaining the iconic and
comfortable charging display style.

D1

Upgraded scOS 2.0, not only optimizing the system
with a new dimension level,
also further improved the system stability.
New features including DC Power mode,
dark mode, battery scrap and more.
Streamline support with BattGo and SmartPower,
for further interconnection to ISDT ecosystem
product information exchange.

Adjustable Digital Power Supply.

In adjustable digital power supply mode,
the Max. power is AC 100W / DC 120W.
CC: 0.2~5.0A
CV: 5~24V

K1

Introducing the dark mode.

scOS 2.0 new dark mode feature,
Suitable for low light scenario,
System will adjust the interface in dark tone,
Reduce light damage to user’s eyes.
While remaining the iconic and
comfortable charging display style.

K1 K1

Signature original creative interactive systems

Serve 152 countries and regions,
Support on line upgrading for more languages, and better interactive system for global market.

K1

Signature original creative interactive systems

Serve 152 countries and regions,
Support on line upgrading for more languages, and better interactive system for global market.

K1

Specifications

Input voltage: AC 100~240V / DC 10~30V
Output voltage: DC 1~26.4V
Max. input current: DC 20A
Charging current: 0.1~10.0A x2
Balance current: 0.5A/Cell Max
Max. charging power: AC 100W / DC 250W x2
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Supported battery types and cell count: LiFe, Lilon, LiPo, LiHv 1-6S, Pb 1-12S; NiMH/Cd 1-16S
Working temperature: 0~40℃
Storage temperature: -20℃~60℃
Dimension: 135x115x49mm
Weight: 约485g
