More than more
Faster than faster

Independent multi-channel quick charge

Larger current independent multi-channel quick charge,
Up to 1500mA current output on each slot,
90 minutes quick charge

Various battery type compatibility

All-in-one control for Li-Ion, LiHV, LiFe, NiMH, NiCd and NiZn batteries
Automatic battery type identification with intelligent charge algorithm matching

ATTENTION:The battery type of LiHv,NiZn should be manually selected during the operation.

Professional work modes
Full color LCD, touch panel

Bright 2.4” high resolution screen displays current job parameters and battery performance

Aluminium alloy shell

Internal heat-conductive silica gel cooling system integrated into the aluminium-magnesium alloy shell provides improved heat dissipation guaranteeing stable and reliable fast charging and discharging

Upgradeable Firmware

Just connect the charger to your computer to update to the latest firmware for best performance and new features

Product Specifications
N8 N16 N24
Power input: Type-C Ø6.5 DC jack Ø6.5 DC jack
Input voltage: 5-12V 5-12V 5-12V
Input power: 18W 36W 48W
Charge Cells: 1-8 AA/AAA cells 1-16 AA/AAA cells 1-24 AA/AAA cells
Battery type: Li-lon, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop Li-lon, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop Li-lon, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop
Charge current: 0.1A-1.5A/slot 0.1A-1.5A/slot 0.1A-1.5A/slot
Discharge current: 0.1A-1.0A/slot 0.1A-1.0A/slot 0.1A-1.0A/slot
Display: 240×320 IPS LCD 240×320 IPS LCD 240×320 IPS LCD
Operating temperature: 0°C-40°C 0°C-40°C 0°C-40°C
Size(LxWxH): 188.5x79x28mm 308.4x79x28mm 428.2x79x28mm
Weight: 283g 450g 810g
