Lights off in the dark,
introducing the dark mode.
scOS 2.0 new dark mode feature,
Suitable for low light scenario,
System will adjust the interface in dark tone,
Reduce light damage to user’s eyes.
While remaining the iconic and comfortable charging display style.
Signature original creative interactive systems
Serve 152 countries and regions,
Support on line upgrading for more languager, and better interactive system for global market.
Specifications
| Input voltage | DC 10~30V | DC 10~34V |
| Output voltage | DC 1~26.4V | DC 1~34V |
| Max. input current | 20A | 35A |
| Charging current | 0.2~10.0A x2 | 0.2~20.0A x2 |
| Max. charging power | 250W x2 | 500W x2 |
| Balance current | 0.5A/Cell Max | 1.5A/Cell Max |
| Discharging current | Not support | 0.2~1.5A x2 |
| Max. discharging power | Not support | 15W x2 | Abnormal voltage alarm | Support | Support |
| Incorrect cell count setting alarm | Support | Support |
| Supported battery types and cell count | LiFe, LiIon, LiPo, LiHv 1-6S ; Pb 1-10S ; NiMH/Cd 1-16S |
LiFe, LiIon, LiPo 1-8S ; LiHv 1-7S ; Pb 1-12S ; NiMH/Cd 1-16S |
| Parallel charging power and current | 400W/16A | 800W/35A |
| Parallel discharge power and current | Not support | 30W/3A |
| Input anti-reverse function | Not support | support |
| Output anti-reverse function | Not support | support |
| Input anti-spark function | Not support | support |
| Output anti-spark function | Not support | support |
| Working temperature | 0~40℃ | 0~40℃ |
| Storage temperature | -20℃~60℃ | -20℃~60℃ |
| Dimension | 90.5×90.5x47mm | 105x105x47mm |
| Weight | About 250g | About 350g |
