H605 Air

Smart and compact, 50W/6S balance charger.

H605 AIR

Simple but not simplistic

Bluetooth wireless connection,
One App controls all.

Tiny while powerful

Efficiency circuit, fully silent aluminum alloy cooling.

H605 AIR

Support BattGO smart battery technology

Automatically identify battery chemistry types,
Auto match charging parameters,
One-click start, safe and fast.

New touch screen UI

Optimized touch screen UI for mobile phones,
clearer data display,
and more convenient operation.

OTA firmware upgrade

Mobile App and charger firmware can be OTA upgrade,
more features coming soon.

H605 AIR

H605 AIR

H605 AIR
H605 AIR

H605 AIR

H605 AIR
Specifications
H605 AIR

Input Voltage Range: DC 10~27V
Output Voltage Range: 0.5~28V
Output Current Range: 0.1~5.0A
Max Output Power: 50W
Support Battery Types: LiFe/Lilon/LiPo/LiHv (1-6S),
NiMH/Cd (1-16S), Pb (1-12S)
Balance Cells: 6S
Balance Current: 250mA
USB Output: 5V/1A
System Support: Android 5.0 / iOS 10.3 and above
Bluetooth Support: BLE 4.0 and above
Size: (LxWxH)79×55.7×16.6mm
Weight: 71g


OPERATION INSTRUCTION
