ISDT C4 产品规格参数

Model

C4
Input Power DC 12-24V/2.5A
Circuit Power max. Charge power 25W max. Discharge power 10W
Battery Count 1 – 4 single cells, cylindrical
Battery Size AAA,AA,10440,10500,12500,12650,
13500,13650,14500,14650,16650,
17650,18650,20650,22650,26650
Operating Voltage Range 0.2V – 5.0V/slot
Battery Chemistry Type NiMH, NiCd, NiZn, Eneloop, Li-Ion, LiHv, LiFePO4
Charge Current Range 0.1A – 3.0A/slot
Discharge Current Range 0.1A – 1.5A
Operation Modes Charge, Discharge, Storage, Cycle, Activation, Analysis
Cycle Count 1 – 66 cycles
Display 320×240 IPS LCD
Beep Sound Multi-tone
Temperature Sensors 5 for inner

Operating Temperature 0℃ – 40℃
Calibration Factory calibration
Voltage Measurement ±10mV internal resolution
Current Measurement ±10mA internal resolution
Standby Current Drain <0.05mA/battery
External Ports DC Input, Micro USB Link, USB power output
USB Power Output DC 5V / 2.1A
Firmware Update Yes
Reverse polarity protection support
Over temperature protection support
Over capacity protection support
Dimensions (L×W×H) 122×85×38mm
Material PC+ABS casing, aluminum heatsink
Weight 153g(approx.)
